Computers Follow Instructions

Overview

In this activity you will write, run, and debug a program that navigates a robot to a specific location on the Foundations field and stops. That sounds simple — and the goal is simple — but the path from idea to working program will reveal something important.

By the end of this activity you will be able to:

• Define algorithm and explain why order matters in a sequence of instructions.
• Write a precise, step-by-step program that moves a robot to a target zone.
• Use a structured debugging process to find and fix errors in your code.
• Connect robot behavior to the AI literacy idea that all intelligent systems begin with instructions.

Commands You Will Use

These are built-in commands the robot already understands. You will use them inside your program. You don’t have to write them — they come with the controller.

Phase 1 — Activate: The Literal Robot

The Sandwich Test

Before you program a robot, it helps to feel what it is like to be one. A robot follows every instruction exactly as written. It cannot guess what you meant. It does only what you said — even when that is obviously not what you wanted.

My sandwich instructions (write them first):

Reading them back literally, what would go wrong?

Why would the robot do something you did not intend? What does that tell you about instructions?

Phase 2 — Concept: What Is an Algorithm?

An algorithm is a precise, ordered sequence of instructions that tells a system exactly what to do. Every program you write is an algorithm. Every autonomous robot runs an algorithm.

Four Properties of a Good Algorithm

1. Complete — every step needed to finish the task is included.
2. Ordered — the steps happen in the right sequence.
3. Precise — each step is specific enough that it can be followed without guessing.
4. Correct — following the steps produces the intended result.

Inputs and Outputs

Every algorithm takes inputs (information it needs) and produces outputs (the result). For a robot navigation program:

In your own words: what is the difference between an algorithm and just a list of ideas?

Phase 3 — Plan

Mission 1 — Waypoint Alpha Requirement

Step 1 — Field Orientation

Before writing code, you need to know where things are. Measure or estimate these values on the real field and record them here.

Step 2 — Write Your Algorithm in Plain English

Write your plan as a numbered list. Do not write code yet. Be specific enough that someone who has not seen the field could follow your instructions.

Phase A: Travel to Waypoint Alpha

Phase B: Stop in the zone

Phase C: Return to starting box (Bonus Mission)

Step 3 — Predict

Before you run anything: what do you predict will go wrong on the first try, and why?

Phase 4 — Build & Run

Starting Code Template

Type this program into your robot controller exactly as shown. Each line has a comment (after the //) that explains what it does. The comments are notes for you — the robot ignores them.

// Unit 1, Big Idea 1: Waypoint Navigator
// Name: _______________________   Date: ___________

#include <kipr/wombat.h>

int main()
{
	motor(0,100);  //this turns one of the motors on
	motor(3,100);  //this turns the other motor on
	msleep(1000);  // hold still so the stop is visible
	ao();          // turns the motors off after the msleep has completed
	// Add your Bonus Mission call here when ready.
	return 0;
}

Before You Press Run — Checklist

• Your program is typed in exactly as shown, with no missing semicolons
• Robot is fully inside the starting box
• You know exactly what “success” looks like before the run starts
• You are watching to see whether the robot reaches the zone and stops

Phase 5 — Debug

Debugging is not guessing. It is a structured process of observation, hypothesis, and testing. Every time something goes wrong, use this process instead of randomly changing numbers.

Structured Debugging — Four Questions

1. OBSERVE: What exactly happened? (Not “it didn’t work” — be specific.)
2. COMPARE: What did you expect to happen? What was the gap?
3. HYPOTHESIZE: What is the most likely cause of that gap?
4. TEST: Change one thing, run again, and record what changed.

Trial Log

Complete one row for every run. Never skip a row — even failed runs contain information.

Describe one specific bug you found. What was the symptom? What was the cause? How did you fix it?

Phase 6 — Connect: The AI Literacy Bridge

Your robot did not decide to navigate to Waypoint Alpha. It followed the instructions you wrote. Every intelligent system — from a robot to a recommendation engine to a self-driving car — begins with someone writing instructions that tell the system what to do and how to do it. The quality of the system depends directly on the quality of those instructions.

Read each scenario below. Think it through, then write a short answer.

A navigation app tells you to turn right — into a wall. Who wrote the instructions that caused this? What probably went wrong?

A spam filter marks an important email as junk. What does this tell you about the instructions the filter was given?

In both cases above — and in your robot runs today — who is responsible for fixing the instructions? What does that mean for how we should think about AI systems?

Phase 7 — Individual Reflection

Complete this section on your own.

1. What is an algorithm? Write a definition in your own words — do not use the word “instructions.”

2. What was the most important variable in your program today? How did changing it affect the robot’s behavior?

3. Precision matters in algorithms. Give one example from today where being imprecise caused a problem, and explain how you fixed it.

4. Complete this in 2–3 sentences: “Intelligent systems require instructions before they can act. This means that when an AI system makes a mistake…”

Extension Challenges

Finished early? Try one or more of these.

Extension A — Precision Tuning

• Add a third integer variable called SPEED to your program and connect it to your motor calls.
• Run 5 trials at SPEED = 30, then 5 at SPEED = 70.
• Record how speed affects your travel time. What relationship do you notice?

Extension B — The Pause Problem

• The rules say the stop must be clearly visible. What is the minimum pause value that reliably gets credit?
• Design an experiment: run 5 trials at each of three different pause values.
• What is the minimum pause you would use in a real competition run, and why?

Extension C — Sequence Matters

• What happens if you tell the robot to drive back before it ever reaches Waypoint Alpha? Predict the outcome, then test it.
• Why does sequence matter in an algorithm? Write 2–3 sentences connecting this to how AI systems are designed.

Extension D — Inputs as Numbers

• Change the two motor power numbers and the msleep number, and predict what each change will do before you run it.
• What advantage does changing a number at the top give you over changing it in many places?

Extension E — Blocks vs. Text

• If you’ve used a block-based tool before (Scratch, Blockly, etc.), compare it to the C you just wrote. What can you do in C that blocks make awkward? What did blocks make easier?
• Why might a real robot controller prefer a text language like C over a block-based one?

Extension F — Why a PIN?

• Every lab in this course has asked for your PIN before you could submit. That’s a simple password system protecting your identity so no one else’s work gets mixed up with yours.
• What’s one weakness of a short numeric PIN compared to a longer password? If someone guessed your PIN, what’s one change to this system that would make that harder — and how would that change actually fix the weakness you named?
